VIVAX TV-40LE113T2S2SM CV6681H-A42 EMMC KLM8G1GETF-B041

vivax tv-40le113t2s2sm cv6681h-a42 emmc klm8g1getf-b041 BOARD TV BOARD CV6681H-A42 KLM8G1GETF-B041 EMMC FIRMWARE BOARD CV6681H-A42 BOARD EMMC PROGRAMMER TNM 5000 READ EMMC KLM8G1GETF-B041(ISP) BOARD CV6681H-A42 crystal 24.000 MHz PINS 1 and 2 connect with GND. tv must be in 220v plug. and read EMMC. no need for extra voltage. 3.3v and 1.8v. for reading EMMC TNM5000 […]

Solid horizontal lines on screen

Dear All, Please see below videos. There are solid horizontal lines on the screen. Could you please advise what should I do?   Thank you in advance.   Kind regards, Elnur Aliyev

E-TECH 50LR550AD MSD6A638-T8E2 EMMC BIN Firmware

e-tech 50lr550ad msd6a638-t8e2 emmc bin firmware power board main board main board model MSD6A638-T8E2 PROGRAMMER TNM5000 ISP READ EMMC THGBMFG6C1LBAIL EMMC ISP INFO ISP INFO READ EMMC PROGRAMMER TNM5000 READ EMMC BOARD MAIN BOARD MSD6A638-T8E2 Programmer ISP Cable EMMC pinISP PIN1 CMDISP PIN3 RST-n(Reset) (mandatory)ISP PIN5 CLK (Clock)ISP PIN6 DAT0ISP PIN8,10 VSS (GND)Vcc of Chip […]
