GRUNDIG 50GEU7800B ZAE190R-2 EMMC FIRMWARE

April 12, 2024

Share post with Friends

grundig 50geu7800b zae190r-2 emmc firmware download GRUNDIG 50GEU7800B ZAE190R-2 EMMC FIRMWARE ZAE190R-2 emmc pinout

MAIN BOARD ZAE190R-2

emmc pinout

to see EMMC pinout photo as well as to download EMMC BIN Firmware. you must subscribe

isp emmc programmer tnm5000

ISP INFO READ EMMC PROGRAMMER TNM5000 READ EMMC BOARD ZAE190R-2

Programmer ISP Cable EMMC pin ISP PIN 1 CMD ISP PIN 3 RST-n(Reset) (mandatory) ISP PIN 5 CLK (Clock) ISP PIN 6 DAT0 ISP PIN 8, 10 VSS (GND) Vcc of Chip Must be ON. Reset is needed only when circuit reset is not working.

PINOUT EMMC READ RT809H

to see EMMC pinout photo as well as to download EMMC BIN Firmware. you must subscribe

PINOUT EMMC READ XGecu T56

My channel YouTube RepairAllTV

DUMP EMMC NAND EEPROM
Important notes: The files we make available on this website are backup copies of device firmware that were fully operational at the time of copying.
We always try to refer to the technical data of the device, however we inform you that there may be some incompatibility with your device, even if it is the same model.
Firmware is generally fully compatible, but users should be aware that there is a possibility of incompatibility.

You need an programmer to write this dump to the chip.
Please remember to back up your firmware to restore in case of any errors or incompatibilities.

GRUNDIG MODEL 50GEU7800B

MAIN BOARD ZAE190R-2

EMMC THGBMNG5D1LBAIL Size: 3.69GB

PANEL 50T32-SOC XL BD

READ EMMC PROGRAMMER TNM5000 AND XGecu T56
