sunny sn50fil403/0216 tp.ak706S.pc822 emmc firmware SUNNY SN50FIL403/0216 TP.SK706S.PC822 EMMC firmware
SUNNY board TP.SK706S.PC822
to see EMMC pinout photo as well as to download EMMC BIN Firmware. you must subscribe
ISP INFO READ EMMC PROGRAMMER TNM5000 READ EMMC BOARD TP.SK706S.PC822
Programmer ISP Cable EMMC pin
ISP PIN 1 CMD
ISP PIN 3 RST-n(Reset) (mandatory)
ISP PIN 5 CLK (Clock)
ISP PIN 6 DAT0
ISP PIN 8, 10 VSS (GND)
Vcc of Chip Must be ON. Reset is needed only when circuit reset is not working.
EMMC PINOUT
PROGRAMMER RT809H ISP READ EMMC AND XGeeu T56
PT500GT02-4-C-3
SUNNY Android 11
My channel YouTube RepairAllTV
DUMP EMMC NAND EEPROM
Important notes: The files we make available on this website are backup copies of device firmware that were fully operational at the time of copying.
We always try to refer to the technical data of the device, however we inform you that there may be some incompatibility with your device, even if it is the same model.
Firmware is generally fully compatible, but users should be aware that there is a possibility of incompatibility.
You need an programmer to write this dump to the chip.
Please remember to back up your firmware to restore in case of any errors or incompatibilities.
SUNNY SN50FIL403/0216 TP.SK706S.PC822 EMMC firmware
SUNNY SN50FIL403/0216
BOARD TP.SK706S.PC822
EMMC KLM8G1GETF-B041 Size: 7.28 GB
PT500GT02-4-C-3
READ EMMC PROGRAMMER TNM5000/ RT809H, AND XGeeu T56
attention. first unzip (part 2.) then part 1
download only eeprom or dump or nand flash emmc. here Subscription
Subscription more here (Select subscription plan)
